Brand Name: | HXCOWO |
Model Number: | HX-SW5 |
MOQ: | 50 meters |
Price: | Negotiable |
Packaging Details: | Wooden shaft+Export cardboard box |
TECHNICAL PARAMETERS | ||||
Fiber Core Number | Diameter (mm) | Weight (kg/km) | ||
2-36 | 13.9 | 202 | ||
38-72 | 15.1 | 241 | ||
74-96 | 17.1 | 290 | ||
98-120 | 18.6 | 333 | ||
122-144 | 20.2 | 281 |
Allowable Tensile Force Long Term/Short Term (N) | Allowable Pressure Long Term/Short Term (N/100mm) | Allowable Pressure Long Term/Short Term (N/100mm) | |||
1000/3000 | 1000/3000 | 1000/3000 | |||
Scope of application | Suitable for long-distance communication and inter-office communication | Fiber type | G652D | ||
Laying method | Direct burial | Operating temperature | 40℃-70℃ |
